CF-R5 CF-R6 CF-T5 CF-W5 CF-Y5
processor Intel Centrino
Solo
U1400 1,2GHz		 Centrino Duo U2400 1.06GHz Intel Centrino
Duo
L2500 1.86GHz
geheugen 512Mb DDR 2 (expandable up to 1536Mb)
scherm 10,4" 10,4" 12,1" touch screen 12,1" 14,1"
scherm resolutie  1024x768 1024x768 1024x768 1024x768 1400x1050
DVD none DVD+/RW
harddisk 60Gb 60Gb 60Gb 60Gb 60Gb
gewicht 990g 930g 1260g 1199g 1490g
afmetingen 229x187x
(29x42)		 229x187x
(29x42)		 268x210x
(25x44)		 268x210x
(25x44)		 309x243x
(24x44)
batterijduur max 10h 2 max 9h 2 max 14h 2 max 10h 2 max 11 h 2
OS XP Pro SP2 or Vista Business

Chipset
- Intel 945 GMS graphic chip controller, UMA
(unified memory architecture) tot en met 128 MB

Interfaces
- External Display (VGA port): Mini D-sub, 15-pin
- Headphone: Mini-jack (stereo)
- Microphone: Mini-jack (stereo)
- DC In: Jack
- USB 2.0: 2x 4-pin
- Modem: RJ-11
- LAN: RJ-45
- Mini port replicator: 50-pin

Expansion Slots
- PC card slot: 1x type II
- SD card slot: 1x
- Optional RAM module: 1x Micro DIMM

Wireless
- WLAN: Intel® PRO/Wireless 3945 ABG netwerk verbinding ,
  ondersteunt  IEEE 802.11a/b/g (max. 54 Mbps)

[1] gemiddeld gewicht, afhankelijk van de geinstalleerde opties
[2] batterij volgens de JEITA batterijduur meetmethode (Ver.1.0)
