Datasheet

ZNYX ZX7000

48-port PICMG 3.0 /3.1 ATCA Hub Board, PTMC Carrier

Main Features:

• 48-port GigE Non-Blocking Switch Fabric
  Supports 14 or 16 slot ATCA chassis ,12 or 14 PICMG 3.0 Base Interface Ports,8 or 12 PICMG 3.1 Option 2 Ports,Up to 12 GigE Egress RJ-45 Ports,Switch-Switch Link,Shelf Manager (ShMC) Link
• Two PMC/PTMC, Option 5 GigE sites (2.0Gb/s)
• Optional RTM
  Two RS-232 Management Ports,Two 10/100 Ethernet Management Ports,Six Switched GigE RJ-45 Ports
• OpenArchitect 3 w/ Linux Kernel
• Wire-speed L2/L3 Switching
• Wire-speed L2 - L7 Packet Classification

Product Overview:

The ZX7000 is a 48-port AdvancedTCA™ Hub board / PTMC Carrier, providing switched Gigabit Ethernet service for up to 14 node boards via the PICMG 3.0 Base Inteface and PICMG 3.1 Fabric Interface. The ZX7000 provides a tightly integrated modular switching platform that enables high-density solutions with the addition of onboard PMC/PTMC sites.
Linux-based OpenArchitect® 3 runs on the embedded Freescale MPC8270VR, providing a comprehensive package for the management of Layer 2 and Layer 3
packet switching. VLAN management and Layer 2-7 packet classification are also included with a user-friendly interface. OpenArchitect may be used with a variety of IP routing protocols.
Up to 12 switch egress ports are provided, depending on chassis/switch configuration, and one port is dedicated to the switch-to-switch connection in redundant configurations. For additional management connections, a USB, RS-232 serial, and three out-of-band 10/100 Ethernet ports are available for local configuration.
Two standards-based PMC/PTMC slots allow for significant expansion of possible applications. Each slot may host additional memory, I/O, processing or packet-processing capability.

Fault Tolerant Backplanes:

Two ZX7000 AdvancedTCA™ switches can be used in a standard ATCA chassis to implement a fully redundant dual star network architecture over the base and fabric interface. Each payload slot has two Base Interface connections, one to each switch. With the OpenArchitect High Availability (HA) software suite, the chassis can respond and automatically correct any single point of failure.

Ordering Information:

• ZX7000
  48-port GigE PICMG 3.0 / 3.1 Hub Board, PTMC Carrier, Layer 2-7 Operationn
• ZX6000RTM
  Rear Transition Module for the ZX7000 includes: 2 OOB RS-232 ports, 2 OOB 10/100 BaseT ports, six in-band 10/100/1000 BaseT ports, and telco-clock generator mezannine connector
• ZX6000PE2
  PTMC Egress Card provides 2 in-band 10/100/1000Base-T ports.
• ZX6000PE4
  PTMC Egress Card provides 2 to 4 10/100/1000Base-T ports. and OOB management.
